Aries Series Touch Screen Systems



Embedded System Legacy Design - Please Note: Due to the tremendous shortage in the supply change of semiconductors, these units can have an extended lead time. Please get in touch with us for lead time and new designs.

Industrial Touch Screen Computer and Systems

fan less · no mechanical moving parts - maintenance free · long term availability

Touch Technology

  • Resistive
  • Capacitive
  • Infrared


Ascend Electronics Aries Touch Screen PC and systems are available in closed and open frame versions and feature all the functionality of the standard Ascend Electronics embedded systems. Many system versions meet Protection Class IP68 and many systems are especially well suited for in- and outdoor applications such as interactive information terminals. Thanks to a sophisticated mechanical design many of our Aries Touch Screen Series units can be installed flush with the front from the rear of a system and thus provide protection against vandalism and other forces. Systems are built for extended ambient temperatures going as low as -30°C up to +70°C



Touch Panel PC & Touch Displays Summary Sheet


Display Size From 6.5” to 19”
Display Types TFT High Resolution, High Brightness Displays
Touch Types Resistive, Infrared Touch
Processors ARM9, ARM11, LX800, Vortex x86, PC Intel Atom,
On board Ram Up to 2GB soldered
Flash On Board Up to 16MB soldered
Available Interfaces on Board PS/2 (Mouse/Keyboard), Ethernet 10/100/1000M, USB, RS485, RS232, CAN
Other Features Socket for: Compact Flash, SRAM, NVRAM, EEPROM Low Power Consumption, Extreme Rugged Design RTC, Watchdog, Temperature Control Monitoring Extended Temperature Versions Preloaded OS (BSP for Windows Embedded, CE and Linux)

Touch Panel PC & Touch Displays Summary Sheet



Display Size From 6.5” to 19”
Display Types TFT High Resolution, High Brightness Displays
Touch Types Resistive, Infrared Touch
Processors ARM9, ARM11, LX800, Vortex x86, PC Intel Atom,
On board Ram Up to 2GB soldered
Flash On Board Up to 16MB soldered
Available Interfaces on Board PS/2 (Mouse/Keyboard), Ethernet 10/100/1000M, USB, RS485, RS232, CAN
Other Features Socket for: Compact Flash, SRAM, NVRAM, EEPROM Low Power Consumption, Extreme Rugged Design RTC, Watchdog, Temperature Control Monitoring Extended Temperature Versions Preloaded OS (BSP for Windows Embedded, CE and Linux)
